Description, Specifications for Synology FlashStation FS3600
FlashStation FS3600
Accelerate your business with an affordable all-flash solution
Fast and scalable all-flash NAS
FS3600 is a 24-bay all-flash Synology NAS for enterprise use that boosts the performance of I/O sensitive applications, such as databases, virtual machines, or online transaction processing (OLTP). Featuring a 12-core CPU and high-speed network connection, FS3600 delivers over 195,000 iSCSI 4K random write IOPS1 to satisfy enterprise demand for high-speed infrastructure.
CPU
Intel® Xeon® D-1567 12-core 2.1 GHz
Memory
16 GB DDR4 ECC RDIMM, up to 128 GB
Scalability
Up to 72 x SAS/SATA drives
PCIe expansion
High-performance NIC support
Fully certified storage virtualization solutions
Synology iSCSI storage fully supports most virtualization solutions to enhance work efficiency with easy management interface. VMware vSphere 6 and VAAI integration helps offload storage operations and optimizes computation efficiency. Windows Offloaded Data Transfer (ODX) speeds up data transfer and migration rate. OpenStack Cinder support turns your Synology NAS into a block-based storage component.
5-year warranty
As we're committed to improving product innovation and quality, Synology guarantees a robust and reliable data management experience with a 5-year limited warranty, providing responsive technical support and hardware replacement services to maximize your return on investment.
Real-time collaboration on your private cloud
Synology Office is a collaboration package combining the convenience and usability of the public cloud with private cloud privacy and security. It enables seamless collaboration on documents and spreadsheets in a protected environment.
Btrfs: Next generation storage efficiency
Btrfs file system introduces the most advanced storage technologies to meet the management needs of modern large scale businesses:
Flexible Shared Folder/User Quota System provides comprehensive quota control on all user accounts and shared folders
Snapshot Replication provides schedulable and storage capacity-saving data protection with 1,024 shared folder backups and 65,000 system-wide snapshots
File or folder level data restoration makes data recovery fast and flexible
Automatic file self-healing detects and recovers corrupted files without user intervention
Powered by Synology DSM
Synology High Availability
Seamless transition between clustered servers in the event of a server failure to minimize the impact on applications.
Active Backup Suite
Integrated, modern, and license-free backup & instant recovery solution for VMware, Windows, Office 365, and G Suite.
Virtual Machine Manager
Run various operating systems in isolated sandboxes. Seamlessly clone, restore and migrate virtual machines.
Synology MailPlus
Secure, reliable, and private mail server solution with an intuitive and modern mail client.
Security
Comprehensive built-in security tools are constantly updated to protect your devices against evolving threats.
Snapshot Replication
Schedulable and instantaneous data protection of shared folders and iSCSI LUNs for quick disaster recovery.
- Power button and indicator
- Beep off button
- Drive status indicator
- Drive tray
- Power port
- PSU indicator
- PSU fan
- Console port
- 1GbE RJ-45 port
- 10GbE RJ-45 port
- USB 3.0 port
- PCIe expansion slot
- Expansion port
- Reset button
CPU |
CPU Model | Intel Xeon D-1567 |
|---|---|---|
| CPU Architecture | 64-bit | |
| CPU Frequency | 12-core 2.1 (base) / 2.7 (turbo) GHz | |
| Hardware Encryption Engine (AES-NI) | ||
Memory |
System Memory | 16 GB DDR4 ECC RDIMM |
| Memory Module Pre-installed | 16 GB (16 GB x 1) | |
| Total Memory Slots | 4 | |
| Memory Expandable up to | 128 GB (32 GB x 4) | |
| Notes |
|
|
Storage |
Drive Bays | 24 |
| Maximum Drive Bays with Expansion Unit | 48 (RX1217sas x 2) / 72 (FX2421* x 2) | |
| Compatible Drive Type* |
|
|
| Maximum Internal Raw Capacity | 92.16 TB (3.84 TB drive x 24) (Capacity may vary by RAID types) | |
| Maximum Raw Capacity with Expansion Units | 276.48 TB (92.16 TB + 3.84 TB drive x 48) (Capacity may vary by RAID types) | |
| Maximum Single Volume Size* |
|
|
| Hot Swappable Drive | ||
| Notes |
|
|
External Ports |
RJ-45 1GbE LAN Port | 4 (with Link Aggregation / Failover support) |
| RJ-45 10GbE LAN Port | 2 (with Link Aggregation / Failover support) | |
| USB 3.0 Port | 2 | |
| Expansion Port | 1 | |
PCIe |
PCIe Expansion | 1 x Gen3 x8 slot (x8 link) |
| Add-In-Card Support | PCIe Network Interface Card | |
File System |
Internal Drives |
|
| External Drives |
|
|
| Notes | exFAT Access is purchased separately in Package Center. | |
Appearance |
Form Factor (RU) | 2U |
| Size (Height x Width x Depth) | 88 mm x 482 mm x 724 mm | |
| Weight | 14.9 kg | |
| Rack Installation Support* | 4-post 19" rack (Synology Rail Kit - RKS1317) | |
| Notes | The rail kit is sold separately | |
Others |
System Fan | 80 mm x 80 mm x 4 pcs |
| Fan Speed Mode |
|
|
| Easy Replacement System Fan | ||
| Power Recovery | ||
| Noise Level* | 57 dB(A) | |
| Scheduled Power On / Off | ||
| Wake on LAN / WAN | ||
| Power Supply Unit / Adapter | 500 W | |
| Redundant Power Supply | ||
| AC Input Power Voltage | 100 V to 240 V AC | |
| Power Frequency | 50/60 Hz, Single Phase | |
| Power Consumption* | 258.23 W (Access) 127.99 W (HDD Hibernation) |
|
| British Thermal Unit | 881.12 BTU/hr (Access) 436.72 BTU/hr (HDD Hibernation) |
|
| Notes |
|
|
Temperature |
Operating Temperature | 0°C to 35°C (32°F to 95°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) | |
| Relative Humidity | 5% to 95% RH | |
Certification |
|
|
Warranty |
5 Years | |
| Notes | The warranty period starts from the purchase date as stated on your purchase receipt. | |
Environment |
RoHS Compliant | |
Packaging Content |
|
|
Optional Accessories |
|
|
| Notes | It is required to use D4RD-2666-16G with identical memory modules of the same capacity and frequency. | |
